Ceramic ball mill

Ceramic ball mill

Cylinder speed:14-36r/min
Weight:3-18.6t
Motor power:5.5-90kw
Ceramic ball mill is mainly used for mixing, grinding process. It can be used both in dry grinding process and wet process. Based on different production needs, it can adopt diffrent lining plates. Fineness of final products depend upon the grinding time. Motor startup with automatic voltage reducing to reduce the start current. Its structure is divided into integral and independent type.

Introduction


Ceramic ball mill is mainly used for mixing, grinding process. It can be used both in dry grinding process and wet process. Based on different production needs,
 it can adopt diffrent lining plates. Fineness of final products depend upon the grinding time. Motor startup with automatic voltage reducing to reduce the start current. Its structure is divided into integral and independent type.



Principle

The ball mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through
 the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber.
The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials.
The ground materials are discharged through the discharging board thus the grinding process is finished.


Advantages:Inquiry > >


1Fast rotational speed, high efficiency and fine granularity
2.Most professional Ceramic grinder
3.Stable performance
4.Most Competitive Price

Technical Parameters:Inquiry > >

Type Capacity
(t/h)
Cylinder speed
(r/min)
Motor power
(kw)
Weight
(t)
TCQ910×1120 0.2 36 5.5-11 3.0
TCQ1200×1400 0.5 32 11-18.5 3.8
TCQ1500×1800 1.0 28 15-22 4.5
TCQ1800×2100 1.5 26 18.5-30 6.0
TCQ2100×2100 2.5 22 22-37 7.4
TCQ2200×2400 3.0 20 28-45 8.2
TCQ2500×2900 5.0 16 37-55 9.3
TCQ2800×3700 8.0 14.5 55-75 12.5
TCQ3000×3700 10 14 75-90 18.6
